Raypak - Heater Parts - R106A - R156A

In stock

SKU

HTR-R106A-R156A-PTS-GROUPED

Grouped product items
Key	Product Name	Add Qty
1-B	PTS-003903F (Pilot Orifice Natiid-Kit)	Out of stock
1-B	PTS-004078F (Pilot Tube 34"-Kit)	- +
1-B	PTS-004308F (Pilot Orifice Proiid-Kit)	Out of stock
1-B	PTS-004817B (Electronic Ignitioncontrol W/O Lockout-Kit)	- +
1-B	PTS-004818B (Electronic Ignitioncontrol W/Lockout-Kit)	- +
1-B	PTS-005899F (Thermal Cut-Off Fuse-Kit)	- +
1-B	PTS-006714F (Sensor Adapter Pool-Kit)	- +
1-B	PTS-006716F (Bypass Valve Pool-Kit)	- +
3-B	PTS-006717F (Bypass Dam/Shaft-Kit)	- +
3-B	PTS-006721F (Drain Plug Pool-Kit)	- +
3-B	PTS-006723F (Connector & Nut Cpvc2" (2)-Kit)	- +
3-B	PTS-006724F (O Ring Inlet/Outletpool-Kit)	- +
1-C	PTS-006725F (High Limit 135Fauto Reset Surface Mtg-Kit)	- +
2-C	PTS-006736F (Transformer 120/240V-Kit)	- +
3-C	PTS-006737F (Pressure Switch 1.75Psi-Kit)	- +
4-C	PTS-006886F (Thermostat Knob Stop-Kit)	Out of stock
5-C	PTS-008091F (Prv 125 Psi-Kit)	Out of stock
6-C	PTS-008259F (Flange Nut 1/4-20-Kit)	Out of stock
8-C	PTS-009133F (Pressure Switch 11Psi-Kit)	- +
9-C	PTS-009493F (Rocker Switch Spst-Kit)	- +
10-C	PTS-009499F (Control Knob Mv-Kit)	- +
1-G	PTS-009577F (Temperature Sensoriid Three Wire-Kit)	- +
1-G	PTS-011585F (Thermostat Pool-Kit)	- +
1-H	PTS-011586F (Potentiometer Tempcontrol-Kit)	- +
1-H	PTS-011587F (Temp Sensorelectronic Two Wire-Kit)	- +
2-H	PTS-011594F (Hdr In/Out Polymerpool 130-Kit)	Out of stock
2-H	PTS-011595F (Hdr In/Out Polymer130 106A-156A-Kit)	- +
3-H	PTS-011596F (Hdr Return Polymer130 106A-156A-Kit)	- +
4-H	PTS-011600F (O Ring Gasket (2)130 106A-156A-Kit)	- +
4-H	PTS-011601F (Bypass 130-Kit)	- +
6-H	PTS-011602F (Bypass Spring 130-Kit)	- +
7-H	PTS-011605F (Transformer 120/240V130 106A-Kit)	- +
8-H	PTS-011609F (Line Cord 120V Pool-Kit)	Out of stock
9-H	PTS-10010000345 (KIT-PC BOARD CONTROLLER IID)	- +
9-H	PTS-013733F (Fuse 5 Amp Pc Board-Kit)	- +
10-H	PTS-014841F (Tray/Man 106A Nat1.30Mm-Kit)	- +
11-H	PTS-014842F (Tray/Man 156A Nat1.30Mm-Kit)	- +
12-H	PTS-014845F (Tray/Man 106A Pro.84Mm-Kit)	- +
13-H	PTS-014846F (Tray/Man 156A Pro.84Mm-Kit)	- +
14-H	PTS-014849F (Burner Tray 106A Nat1.30Mm-Kit)	- +
15-H	PTS-014850F (Burner Tray 156A Nat1.30Mm-Kit)	Out of stock
16-H	PTS-014853F (Burner Tray 106A Pro.84Mm-Kit)	Out of stock
17-H	PTS-014854F (Burner Tray 156A Pro.84Mm-Kit)	Out of stock
1-J	PTS-014857F (Orifice 106A 1.30Mm-Kit)	- +
2-J	PTS-014858F (Orifice 156A 1.30Mm-Kit)	Out of stock
2-J	PTS-014861F (Orifice 106A .84Mm-Kit)	- +
3-J	PTS-014862F (Orifice 156A .84Mm-Kit)	- +
4-J	PTS-014866F (Gasket Lcd Window-Kit)	Out of stock
1-M	PTS-014867F (Gas Valve Nat106A-156A-Kit)	- +
1-M	PTS-014868F (Gas Valve Pro106A-156A-Kit)	- +
2-M	PTS-014869F (Ht Ex 106A Polymer-Kit)	- +
3-M	PTS-014870F (Ht Ex 156A Polymer-Kit)	- +
5-M	PTS-014874F (Tube Bundle 106Apolymer-Kit)	- +
6-M	PTS-014875F (Tube Bundle 156Apolymer-Kit)	- +
7-M	PTS-014882F (Inlet/Outlet Headerdam 106A-156A-Kit)	- +
7-M	PTS-014883F (Control Box Analog Nat 106A-Kit)	Out of stock
8-M	PTS-014884F (Wire/Harness 106A-Kit)	- +
9-M	PTS-014885F (Wire/Harness 156A-Kit)	Out of stock
10-M	PTS-014886F (Control Bezel 156A-Kit)	- +
11-M	PTS-014887F (Switch/Decalmembrane-Kit)	- +
12-M	PTS-014888F (Cover Control Bezel-Kit)	Out of stock
68	PTS-014889F (Pilot Brkt 106A-156A-Kit)	- +
70	PTS-014890F (Ref Block 106A-Kit)	Out of stock
71	PTS-014891F (Ref Block 156A-Kit)	Out of stock
72	PTS-014892F (Jacket Top 106A-Kit)	Out of stock
73	PTS-014893F (Jacket Top 156A-Kit)	- +
74	PTS-014894F (Jacket Left 106A-Kit)	Out of stock
75	PTS-014895F (Jacket Left 156A-Kit)	Out of stock
76	PTS-014896F (Jacket Right 106A-Kit)	Out of stock
77	PTS-014897F (Jacket Right 156A-Kit)	Out of stock
78	PTS-014898F (Jacket Upper Front106A-156A-Kit)	Out of stock
79	PTS-014899F (Jacket Lower Rear106A-156A-Kit)	Out of stock
80	PTS-014900F (Flue Collector 106A-Kit)	Out of stock
81	PTS-014901F (Flue Collector 156A-Kit)	Out of stock
82	PTS-014902F (Jacket Door Raypak/Ruud 106A-156A-Kit)	Out of stock
83	PTS-014903F (Jacket Door Rheem106A-156A-Kit)	Out of stock
84	PTS-014904F (Access Panel106A-156A-Kit)	Out of stock
85	PTS-014905F (Kit-Control Panel 106A)	- +
86	PTS-014906F (Control Panel 156A-Kit)	Out of stock
87	PTS-014907F (Stackless Top 106A-Kit)	Out of stock
88	PTS-014908F (Stackless Top 156A-Kit)	- +
93	PTS-014910F (Stack Adapter 106A-Kit)	- +
94	PTS-014911F (Stack Adapter 156A-Kit)	- +
35	PTS-015548F (Bypass-Kit 156A)	- +
55	PTS-052871F (Deliming 5/8 Tube-Kit)	- +
65	PTS-002003F (Pilot E10 Nat/Pro053-408-Kit)	- +

Below You'Ll Find The Consolidated List Of Replacement Parts For The Rapak Heater Models R106A And R156A.

PTS-013640F Replaced with PTS-10010000345

Details

PTS-013640F Replaced with PTS-10010000345

A consolidated list of replacement parts for the Rapak Heater models R106A and R156A. If you're having difficulty finding the part you need, please reach out to one of our representatives in the contact section below.

More Information

More Information
Enable Product	Enabled
Visibility	Catalog, Search
Part Diagram Key	1-B,1-B,1-B,1-B,1-B,1-B,1-B,1-B,3-B,3-B,3-B,3-B,1-C,2-C,3-C,4-C,5-C,6-C,8-C,9-C,10-C,1-G,1-G,1-H,1-H,2-H,2-H,3-H,4-H,4-H,6-H,7-H,8-H,9-H,9-H,10-H,11-H,12-H,13-H,14-H,15-H,16-H,17-H,1-J,2-J,2-J,3-J,4-J,1-M,1-M,2-M,3-M,5-M,6-M,7-M,7-M,8-M,9-M,10-M,11-M,12-M
